M40
TECHNICAL SPECIFICATION
Steel grade | Blade hardness:
QSX | 440-460 HV
Tooth type | Tooth hardness:
Fully ground, induction hardened | 750 – 800 HV
Tooth rake angle:
10/30 | 9/29 | 7/39
Additional operations:
Special heat treatment | Shot peening | Tensioning
WORKING CONDITIONS
Blade tension:
Acc. to technical specification of machine manufacturer
Feed rate:
Up to 30 m/min
Blade speed:
25 – 50 m/s
Working time:
Up to 4 h between servicing
|
WIDTH H (mm) |
THICKNESS T (mm) |
PITCH P (mm) |
|||
| 1,0 | 1,1 | 1,15 | 1,25 | 22,22 | |
| 35 | ✓ | ✓ | ✓ | ✓ | |
| 38 | ✓ | ✓ | ✓ | ✓ | |
On request we provide band saw blades of different dimensions.
