M42 BIMETAL
TECHNICAL SPECIFICATION
Steel grade | Blade hardness:
QSX | 490 – 520 HV
Tooth type | Tooth hardness:
High-speed steel M42 | 940-990 HV
Tooth rake angle:
10/30 | 9/29 | 7/39
Additional operations:
Special heat treatment | Shot peening | Tensioning
WORKING CONDITIONS
Blade tension:
Acc. to technical specification of machine manufacturer
Feed rate:
Up to 40 m/min
Blade speed:
Up to 50 m/s
Working time:
Up to 8 h between servicing
|
WIDTH H (mm) |
THICKNESS T (mm) |
PITCH P (mm) |
||||||
| 0,9 | 1,07 | 1,14 | 1,27 | 12,7 | 19 | 22,22 | 25,4 | |
| 27 | ✓ | ✓ | ✓ | |||||
| 32 | ✓ | ✓ | ✓ | |||||
| 34 | ✓ | ✓ | ||||||
| 38 | ✓ | ✓ | ✓ | ✓ | ✓ | |||
| 50 | ✓ | ✓ | ✓ | |||||
| 54 | ✓ | ✓ | ✓ | |||||
On request we provide band saw blades of different dimensions.
